Descrizione
| Specification | Value |
|---|---|
| Model | AKZ438-X-D284A |
| Product type | Circulating oil cooling unit / Oil chiller |
| Maximum cooling capacity | 3.8 kW at 50 Hz / 4.3 kW at 60 Hz |
| Main power supply | Three-phase AC 200 V, 50 Hz / 200–220 V, 60 Hz |
| Control circuit supply | 12/24 VDC |
| Oil pump displacement | 24 L/min at 50 Hz / 28.8 L/min at 60 Hz |
| Applicable ambient temperature | 5 to 45 °C |
| Applicable tank oil temperature | 5 to 50 °C |
| Applicable oil viscosity | 1.4–200 mm²/s, ISO VG2–32 |
| Evaporator type | Shell and coil |
| Condenser type | Cross-fin coil |
Descrizione Prodotto
DAIKIN AKZ438-X-D284A è un chiller a ricircolo d’olio della serie AKZ8, destinato al controllo termico di circuiti di lubrificazione e fluidi idraulici a base minerale. Il modello AKZ438 offre una capacità frigorifera massima di 3,8 kW a 50 Hz e 4,3 kW a 60 Hz, con pompa olio da 24/28,8 L/min. Il campo di viscosità supportato da 1,4 a 200 mm²/s lo rende idoneo a oli ISO VG2–32. ([zeushydratech.com](https://www.zeushydratech.com/product/daikin-akz438-8-series-oil-refrigeration-unit/?utm_source=openai))
Product Description
The DAIKIN AKZ438-X-D284A is an AKZ8-series circulating oil chiller for thermal management of lubrication circuits and mineral-oil hydraulic fluids. The AKZ438 platform provides up to 3.8 kW cooling capacity at 50 Hz or 4.3 kW at 60 Hz, combined with a 24/28.8 L/min oil pump. Its specified operating range covers ambient temperatures from 5 to 45 °C, tank oil temperatures from 5 to 50 °C, and oil viscosities of 1.4–200 mm²/s. ([zeushydratech.com](https://www.zeushydratech.com/product/daikin-akz438-8-series-oil-refrigeration-unit/?utm_source=openai))
Applicazioni / Applications
- Raffreddamento dell’olio di mandrini macchina utensile / Machine-tool spindle oil cooling
- Stabilizzazione termica di circuiti di lubrificazione / Lubrication circuit temperature stabilization
- Raffreddamento di fluidi idraulici minerali / Mineral hydraulic fluid cooling
- Macchine CNC e sistemi di produzione industriale / CNC machinery and industrial production systems
