Descrizione
| Specification | Value |
|---|---|
| Product type | Circulation oil cooling unit |
| Model | AZK328-C-D210 |
| Cooling capacity | 2.8 / 3.2 kW |
| Power supply | AC 3-phase 200 / 220 V, 50 / 60 Hz |
| Compressor rating | Equivalent to 0.75 kW |
| Pump discharge | 24 / 28.8 L/min |
| Oil inlet connection | Rc 3/4 |
| Oil outlet connection | Rc 3/4 |
| Oil drain connection | Rc 1/4 with plug stopper |
| Applicable oil viscosity | 1.4 to 200 mm²/s, ISO VG2 to VG32 |
| Operating ambient temperature | 5 to 45 °C |
| Inlet oil temperature | 5 to 50 °C |
| Refrigerant | R410A |
| Dimensions H × W × D | 790 × 360 × 440 mm |
| Noise level | 62 dB(A) |
| Weight | 58 kg |
Descrizione Prodotto
DAIKIN AZK328-C-D210 è un refrigeratore d’olio a circolazione progettato per il controllo termico di circuiti lubrificante e mandrini. La capacità frigorifera di 2,8/3,2 kW, la pompa con portata fino a 28,8 L/min e i raccordi Rc 3/4 consentono l’integrazione in circuiti industriali di ricircolo dell’olio. È idoneo per olio lubrificante e fluido idraulico minerale con viscosità da ISO VG2 a ISO VG32.
Product Description
The DAIKIN AZK328-C-D210 is a circulation-type oil chiller for thermal control of lubricant and spindle oil circuits. It combines 2.8/3.2 kW cooling capacity with a pump flow rate up to 28.8 L/min and Rc 3/4 oil connections for industrial recirculation systems. The unit is suitable for lubricating oils and mineral hydraulic fluids within the ISO VG2 to VG32 viscosity range.
Applicazioni / Applications
- Raffreddamento olio mandrino / Spindle oil cooling
- Circuiti di lubrificazione macchina utensile / Machine-tool lubrication circuits
- Stabilizzazione termica di fluidi idraulici minerali / Mineral hydraulic oil temperature stabilization
- Sistemi industriali a ricircolo d’olio / Industrial oil recirculation systems
